(1)   ISDB-T all Mode, Guard Interval and 3 layers transmission including partial reception are supported

(2)  All modulation, coding rate, time interleave length in Terrestrial Digital TV Broadcasting is supported

(3)  Dual tuners Diversity reception support (optional)

(4)  Supported Channel bandwidth (BW) 6, 7 and 8 [MHz]

(5)   Advanced high definition video decoding(H264/VC-1/MPEG2)

(6)   Advanced standard definition video decoding(H264/VC-1/MPEG2/AVS)

(7)   Advanced multi-channel audio decoding(MPEG 1, 2, MP 3, DD/DD+, AAC/AAC+, and WMA9/WMA9pro)

(8)   Linux, Windows CE, and OS21 compatible ST40 applications CPU (450 MHz)

(9)   32-bit DDR1/DDR2 compatible local memory interface

(10) Power supply voltage 5V/1.5A input,(11) Supported UART / I2C interfaces for command/communication.

(11)  UART supported baud rate : 9600 , 14400 , 19200 , 38400 , 57600 , 115200

(12)  I2C interface support slave/master mode , the transmission rate up to 400k bps.
